| Quantity | AM1168-D |
|---|---|
| 1 | RFQ |
| 10 | RFQ |
| 50 | RFQ |
| 100 | RFQ |
| 200 | RFQ |
| 500 | RFQ |
| 1000+ | RFQ |
Pricing is subject to change without notice.
*Minimum Order Quantity
To submit a quote request click “Add to Quote”. When you have added all desired parts for your quote, click Request Quote and enter your desired quantities.
If you have any questions about lead times or availability please contact our sales team at sales@atlantamicro.com
Pricing shown is for domestic sales only. International prices are not represented, contact local representative for more information.
AM1168-D is a wideband, cascadable amplifier servicing the 15 to 40 GHz frequency range. The device exhibits high gain and P1dB making it an excellent choice for a medium power driver amplifier where high linearity is required. Available as bare die in a 2.10mm x 1.34mm footprint with internal 50Ω matching and DC blocking capacitors, the AM1168-D is a small form-factor solution that can enable low SWaP applications.
AM1168-D is available only in Gel-Paks of QTY 25.
Function
Driver Amplifier
Freq. (GHz)
15 - 40
Gain (dB)
18
NF (dB)
3.6
OIP3 (dBm)
31
Surface Mount
No
Supply (+V)
5
P1dB (dBm)
20
Supply (mA)
204
Module
No
ECCN: In Process
Harmonized Code: In Process
